Speed. Flexibility. Compliance.


- Preselection filters

- Time domain scan

- Tracking generator

- Battery operation

- Pulse protected input

*ER9000 Opt. 00: 10 Hz – 30 MHz
*ER9000 Opt. 01: 10 Hz – 3 GHz
*Very fast FFT scan gapless (2 sec. In Band B, 1 min. In Band C + D)
*Color Touch-Screen Display
*Compliant with CISPR 16-1-1, MIL-STD-461, ANSI C63.2 and FCC
*Compliant with CISPR 14-1 in combination with the Click CA0010 extension
*Lightning-fast full-compliant scanning
*Integrated CISPR pulse generator
*Robust and compact construction, battery operated and with AC / DC power supply
*Free PES (PMM Emission Suite) software with advanced EMC functionality

CISPR 16-1-1 full compliant
Built-in LISN
Gapless FFT
Single input connector
Up to 2W max input power
Low distortion preamplifier

*Full CISPR 16-1-1 compliant 9 kHz - 30 MHz
*FFT-based, gapless EMI receiver and analyzer, 10 Hz – 30 MHz
*Reduces test time from hours to seconds
*User-friendly in stand-alone and with the powerful PMM Emission Suite software

*Modular approach for all budgets
*Full compliance to CISPR 16-1-1 and MIL-STD
*Eliminates long coax cables
*Compact, lightweight, battery operated
*Features all new detectors

*Discontinuous disturbance (click) analysis
*Four independent frequency channels measuring simultaneously
*Each channel with embedded preselector, attenuator and preamplifier
*Designed to fully match CISPR 16-1-1 and CISPR 14-1 Standards
*Highly flexible selection of number of rates, quartiles and runs operating mode
*Test duration reduced to the minimum theoretically achievable
*Built-in two-lines 16A Line Impedance Stabilization Network (LISN)
*User port for driving any external LISNs
*Embedded switch operation counting unit
*CISPR 16-1-1 embedded click and pulse generator output for internal or external use
*Autocheck and calibration
*Stand alone or PC driven operations
*Free PCA PMM Click Analysis software
*Free PCG PMM Click Generation software
*Full IF and QP history 500us resolution
*Compact yet sturdy construction
*140 dBμV (2 W) maximum input level without damage

*9 kHz to 30 MHz frequency range
*Antenna CISPR 12, CISPR 16, CISPR 25, MIL-STD, DO-160 fully compliant
*Internal full CISPR 16-1-1 receiver
*Operates both swept and gapless FFT modes
*Very fast measuring time
*Embedded attenuator, preamplifier and preselectors
*Fiber optic serial link to 9010F series or directly to PC
*Grounding effectiveness auto-diagnostic capability
*On-board tracking generator and antenna CISPR adapter
*Automatic diagnostic and calibration
*Scattering free
*PC software
*RF front-end output
*On-board capacitance meter
*Plug-in rechargeable Li-ion battery
