- Frequency 20 Hz to 2 MHz, with four-digit resolution in any range

- 0.05% basic accuracy with accurate measurement repeatability at low and high impedance

- DC bias enhancement (Keysight Option 001)

- 20 Vrms test signal (Keysight Option 001)

- High-speed measurements at 5.6 ms

- 201 points list measurement sweep

- Versatile PC connectivity (LAN, USB, and GPIB)

- 20 Hz to 300 kHz/500 kHz/1 MHz, with four-digit resolution in any range

- 0.05% basic accuracy with superior measurement repeatability at low and high impedance

- 100 uV to 2 Vrms; 1 uA to 20 mA variable test signal

- DC bias 1.5 / 2 V

- auto-level control

- DC resistance

- 201 points list measurement sweep

- versatile PC connectivity (LAN, USB, and GPIB)

- frequency upgradability

- Frequency range upgradeable to 10 MHz
- Basic accuracy of ±0.05 % for impedance measurements
- Basic accuracy of ±0.03° for phase measurements
- DC bias up to 40 V
- Data logging function

Wide Test Frequency：
-- LCR-8200A:DC, 10Hz~50/30/20/10/5 MHz
-- LCR-8200:DC, 10Hz~30/20/10/5/1 MHz

7" LCD color Display

0.08% Basic Accuracy

Displaying Four Measurement Results Simultaneously From 17 Selectable Measurement Parameters Freely

15 Steps List Measurement

Two Curves Sweep Mode

Equivalent Circuit Model Analysis (LCR-8200A only)

Internal DC Bias Voltage ±12V

USB Storage Available

Precision LCR Meter

2 MHz Precision LCR Meter

SMD test fixture
