An indispensable collection of simulation models for all types of passive and active RF & Microwave devices engineered to enable designers to go from concept to product faster and easier. These models for discrete die, surface mount and packaged devices are a must-have for anyone involved in PCB-based RF & Microwave circuit or module design.

The Modelithics COMPLETE Library also features a substrate library containing measurement-based substrate parameters for many of the most commonly used substrates.

As designs become more compact and complex, the need for full-wave EM simulations of circuits and systems is on the rise. Modelithics assists in meeting this need with Libraries of 3D EM Geometry Models as well as 3D Brick EM Models™.

The integration of Modelithics’ high accuracy scalable parasitic models into the design environments makes EM co-simulation a seamless process, resulting in very accurate model-to-measurement agreement and fewer design iterations.

The 3D models are based on the physical characteristics of each component and can be used in full wave 3D electromagnetic (EM) simulation, including component interaction and effects of parts in close proximity. The 3D models are substrate independent, measurement validated, and enable full-wave 3D EM simulations.

The Modelithics 3D models are available for Ansys HFSS, Cadence Clarity and (coming soon!) Keysight Technologies RFPro.

Modelithics also offers two World-Class GaN Libraries for Qorvo & Macom Devices! The Modelithics Qorvo GaN Library is a collection of precision nonlinear simulation models for Qorvo GaN die and packaged transistor devices. The GaN transistor models offer valuable features to allow for the most current and accurate design techniques, such as variable bias, temperature scaling, self-heating effects and intrinsic I-V sensing. Power-amplifier (PA) designers can take advantage of the Modelithics MACOM GaN Library, which contains nonlinear simulation models for MACOM GaN packaged transistor devices.

Start your next design with the most accurate and well documented GaN models in the industry! The Modelithics Qorvo GaN and Macom GaN Libraries are free to approved customers and available for use in Keysight Technologies’ Advanced Design System (ADS) and Cadence AWR Design Environment.

Modelithics is the industry leader in providing high quality custom modeling and measurement services for RF, microwave and millimeter-wave electronic devices. Since 2001, Modelithics has provided precision measurement and modeling services with unmatched accuracy including a broad array of highest quality, RF/microwave/mm-wave characterization services. We also specialize in utilizing precision characterization data to develop equivalent circuit, black-box, and 3D EM models for linear and non-linear devices.

Linear, bias-dependent small signal, noise and/or non-linear models can be customized for components and devices in chip or packaged format. Models for active and passive surface-mount components are generated using standard or application specific test fixtures to ensure accuracy in the user's design environment.

All models are provided with complete documentation pertaining to the measurement conditions, model-to-measurement comparisons, and typical range of validity. Modelithics has set a new high standard for excellence in RF/MW/mm-Wave model development and support.
